Split violin with aligned half-boxplots and a centered significance label

Draws a split (left/right) violin for up to two groups at a single x-position, overlays per-group boxplots aligned with each half, and optionally annotates the plot with a p-value significance label (e.g., "", "", "", "ns"). The y-axis title is taken from the variable's label attribute when available (via labelled or Hmisc); otherwise the column name is used.

Usage

PlotSplitViolin(
  data,
  Var,
  Group,
  covars = c("Age"),
  nonparametric = FALSE,
  annotation_text = NULL,
  show_ns = FALSE,
  left_group = NULL,
  color_palette = NULL,
  box_offset = 0.11,
  box_width = 0.15,
  star_from = c("quantile", "data_max", "whisker"),
  star_quantile = 0.995,
  star_pad = 0.03,
  headroom = 0.08,
  star_size = 6
)

Arguments

data: A data frame containing Var, Group, and any covariates.
Var: Column of the numeric outcome to plot. Tidy-eval friendly (unquoted or string).
Group: Column of the grouping variable. Must have 1 or 2 unique values. No factor relabeling is performed inside; set levels externally if needed.
covars: Character vector of covariate column names (default "Age"). Use character(0) for no covariates.
nonparametric: Logical. If FALSE (default), compute the p-value using a linear model and an emmeans contrast on Group. If TRUE: with no covariates, use Wilcoxon rank-sum on Var ~ Group; with covariates, first residualize Var on the covariates (no Group), then apply Wilcoxon rank-sum to the residuals by Group. With only one group, no test is performed.
annotation_text: Optional label to draw (e.g., "*", "**", "***", "ns", "★"). If NULL, the label is derived from the computed p-value.
show_ns: Logical; if TRUE, show "ns" for non-significant results when annotation_text is NULL.
left_group: Optional. The Group value to place on the left half. If omitted, the first factor level (or first observed value) is used.
color_palette: Optional color specification. Supply a named vector keyed by Group values; if unnamed, values are interpreted as (left, right).
box_offset: Horizontal offset for the left/right boxplots from the center (single x = 1). Small values (e.g., 0.10-0.14) sit the boxes inside each half.
box_width: Boxplot width (default 0.15). For clean separation, keep box_width <= 2 * box_offset.
star_from: Where to anchor the vertical position of the significance label: one of "quantile" (default), "data_max", or "whisker".
star_quantile: Quantile used when star_from = "quantile" (default 0.995).
star_pad: Fraction of the y-range added above the anchor for the label (default 0.03).
headroom: Fraction of the y-range added to the top limit to avoid clipping (default 0.08).
star_size: Text size for the significance label (default 6).

Value

A ggplot2 object.

Details

Geometry and alignment. Each half of the violin is drawn with gghalves::geom_half_violin(), then two explicit boxplot layers (left and right) are drawn at fixed x-positions (1 - box_offset and 1 + box_offset), so the boxes always align with their corresponding half and color (no dodging flips).

Significance label. When annotation_text is NULL, the p-value is computed as described and converted to "*", "**", "***", or (optionally) "ns". The label is drawn at x = 1 via ggpubr::stat_pvalue_manual(remove.bracket = TRUE). Vertical placement is anchor + star_pad * (range_y), where the anchor is chosen by star_from. The top limit is expanded by headroom so the label never clips.

Axis label. If Var has a label attribute (from labelled or Hmisc), that text is used for the y-axis title; otherwise the column name is used.

Examples

if (FALSE) { # \dontrun{
PlotSplitViolin(df_analysis, Var = Tryptophan, Group = STATUS)
PlotSplitViolin(
  df_analysis, Var = Tryptophan, Group = STATUS,
  left_group = "Seropositive",
  color_palette = c(Seropositive = "#E8A007", Seronegative = "#8C1A45")
)
PlotSplitViolin(df_analysis, Var = Tryptophan, Group = STATUS,
                covars = "Age", nonparametric = FALSE)
PlotSplitViolin(df_analysis, Var = Tryptophan, Group = STATUS,
                covars = "Age", nonparametric = TRUE, show_ns = TRUE)
} # }
